Alat laboratorium teknik sipil Laboratory CBR Test Set (Electric) For determining the bearing ratio of soil
ASTM D-1883  /  AASHTO T-193

Laboratory CBR Test Set (Electric)

Dimension (l x w x h ) : 110 x 70 x 120 cm
Gross Weight               : 200 kg

No Part Qty
1 ELECTRICAL LOADING MACHINE / Electric, 220 V-AC, 1/2 HP, 1 phase,speed 0.05"/ min reversing switch 10.000 lbs cap. 1 Set
2 CBR MOLD / Machine steel, 6" i.d , 7" height , 2" height of collar. 3 Pcs
3 SPACER DISH / Machine steel, 5 12/16" dia, 2.416" height. 1 Pc
4 CUTTING EDGE / Machine steel, sharp edge. 1 Pc
5 CIRCULAR SURCHARGE WEIGHT / Machine steel, 5 7/8" dia 5 lbs weight. 3 Pcs
6 SLOTTED SURCHARGE WEIGHT / Machine steel, 5 7/8" dia lbs weight. 3 Pcs
7 MODIFIED PROCTOR HAMMER / Machine steel, plated, 18" drop height, 10 lbs weight. 1 Pc
8 SWELL PLATE 1 Pc
9 SWELL TRIPOT 1 Pc
10 FILTER PAPER / 6" dia. , 100 sheets / box. 1 Box
11 PROVING RING / 6.000 lbs capacity. 1 Set
12 DIAL INDICATOR / Range 0.01" x 1". 1 Pc
13 SQUARE PAN / Galvanized steel, 65 x 65 x 7.5 cm. 1 Pc
14 THIN BOX / allumunium, 60 gr capacity. 12 Pcs
15 GRADUATED CYLINDER / Plastic, 1000 ml capacity. 1 Pc
16 SCOOP 1 Pc
17 TROWEL 1 Pc
18 STRAIGHT EDGE / 300 mm length. 1 Pc

For determining the bearing ratio of soil
ASTM D-1883  /  AASHTO T-193
